What is AirNavCAD?
AirNavCAD is an online tool specializing in the design of instrument flight procedures under PANS OPS criteria, AR and annex 14. It allows for the representation of protected areas, the geometric construction of flight paths, and the detailed evaluation of obstacles within a CAD environment accessible from any device.
The system has been developed by aeronautical engineers and validated in accordance with ICAO Doc. 9906.
03
Regulatory Compliance
01
ICAO Doc 9905-AR
Airnavacad has the AR module following the criteria of ICAO document 9905 for the design and evaluation of this type of protection area.
02
ICAO Doc. 9906 – Quality Assurance
The software has been validated according to the Quality Assurance Manual for the design of flight procedures, ensuring traceability and consistency in calculations.
03
Annex 14 – OLS Surfaces
The OLS module allows the construction and evaluation of surfaces in accordance with the requirements established in ICAO Annex 14.
04
Regulation (EU) 2017/373
Used by organizations certified as IFPD Providers in compliance with European regulations applicable to air navigation service providers.
05
ICAO Doc. 8168 – PANS OPS
AirNavCAD applies the criteria established in Doc. 8168 for the construction of protected areas and obstacle assessment in instrumental procedures.
